No.

Items

Parameters

1

Model

FJYHM4280-1-2

2

Honing diameter range

φ30mm- φ80mm

3

Stroke depth

550mm

4

Stroke speed

25m/min adjustable

5

 Stroke control type

Servo motor

6

Quantitative /constant pressure

7

 Spindle motor

Frequency inverter/ Servo

8

 Mini feeding unit

0.1um

9

Spindle motor

5.5Kw

10

Spindle speed

80-1500r/min

11

Spindle number

1

12

Wortable type

Translation axis

13

Machine dimenstion

2400×2100×3200 mm

14

Machine weight

4.8T
